epraya.Mulpol#

Mulpol(Hamer, Expe, graph=True)#

Function for the simulation of the EPR spectrum for powder samples of multiple interactive or non interactive systems (from 2 to 4 systems). If there is an interaction between the systems (electron-eletron or hiperfine), solves the total hamiltonian. Otherwise, use the function Calpowder and sums the contributions to the total spectrum.

Parameters:

  • Hamer (Class) – Container for the hamiltonian parameters of the systems.

  • Expe (Class) – Container for the experimental conditions.

  • graph (Bool) – Plots the resulting spectrum.

Returns:

  • fild1 (np.array) – Array of the magnetic field.

  • sumespct (np.array) – Array of the counts of the spectrum.

Example

import matplotlib.pyplot as plt
import epraya as epr
import numpy as np
Ham,Exp,_=epr.Start(2)
Ham.S1=1
Ham.S2=1
Ham.I1=1/2
Ham.I2=1/2
Ham.g1=np.array([2.003, 2, 2])
Ham.g2=np.array([3.003, 3, 3])
Ham.A1=np.array([200, 200, 200])
Ham.A2=np.array([100, 100, 100])
Ham.Hpp1=[0, 10]
Exp.Freq1=9.4
Exp.Points1=4096
Exp.Temperature1=300
Exp.Frange1=[0,800]
B,spc=epr.Mulpol(Ham,Exp)
Plot of the Mulpol function
